MISC | Adhesive Backing

We offer lamination with an adhesive backing for the following materials:

• Acrylic
• Engraving laminate
• Plywood / MDF (all types)
• Solid timber (all types)
• EPDM rubber
• Faux leather
• Mylar
• Plastazote foam
• FULL LISTINGS HERE

By selecting this option alongside your chosen substrate, we will apply a high-quality double-sided adhesive to the reverse side of the material prior to laser processing.

Adhesive Tape Details

The adhesive used is a double-sided tape featuring a paper tissue carrier, coated on both sides with a modified dispersion acrylate adhesive. It provides strong bonding performance along with excellent resistance to temperature, ageing, and plasticisers.

The tape is supplied with a double-sided silicone release liner (yellow/orange in colour).

Following extensive testing and collaboration with a local manufacturer, we have selected this adhesive for its reliable all-round performance. While we have trialled well-known alternatives such as 3M 467/468 and Orafilm 1375, we found these to be less effective on porous and textured materials.

Tape Technical Details

• Thickness (adhesive + carrier) 160 microns
• Temperature resistance -40° C to +140° C
• Loop Tack (FINAT TM 9) 26 N/25 mm
• Adhesive power
  • (FINAT TM 1, on stainless steel, one side covered with 50-micron polyester film)
    23 N/25 mm after 1 min
    25 N/25 mm after 20 min
    27 N/25 mm after 24 h
  • Shear strength* (FINAT TM 8, on stainless steel, one side covered with 50-micron polyester film)
    >72 h at 23° C
    30 min at 70° C
• Temperature resistance (S.A.F.T.) 110° C

• Application temperature > +15° C
